Drip Edge Trim: 1-3/4" Width x 1-1/2" Height x 1/16" Thickness - Covers 3/16" - 1/4" Reveal - 6063-T5 Aluminum

Drip Edge Trim: 1-3/4" Width x 1-1/2" Height x 1/16" Thickness - Covers 3/16" - 1/4" Reveal - 6063-T5 Aluminum Product Information

Drip Edge Trim is used to seal and protect exposed seams on exterior doors and panels. Its angled profile directs water away from the structure, helping to prevent moisture intrusion and finish degradation. Commonly installed on RVs, marine enclosures, and specialty vehicles.

Highlights

• Moisture Deflection – Channels water away from door and panel seams.
• Protective Edge Finish – Seals and covers exposed joints to prevent wear and leaks.
• Exterior-Grade Profile – Built to withstand outdoor conditions and movement.
• Easy to Install – Can be cut and fastened to fit door frames and panels.
• Used in Mobile and Marine Builds – Ideal for RVs, boats, trailers, and specialty work vehicles.

Need custom sizes or extrusions? Check out our customization services.

• Width:1-3/4"
• Height:1-1/2"
• Wall Thickness:1/16"
• Covers:1-7/16"
• Reveal:1/4"
• Alloy & Temper:6063-T5
• Specification Met:ASTM B221-14
• Country of Origin:United States of America
• Yield Strength:16k PSI-1
• Hardness:Brinell 55
• RoHS:RoHS 3 (2017/2102/EU) Compliant
• REACH:REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant
• DFARS:Specialty Metals COTS-Exempt
• Materials:See Specification
Aluminium 95.1%
Chromium 0-.1%
Copper 0-0.1%
Iron 0-0.7%
Magnesium 0.45-.90%
Manganese 0-0.10%
Silicon 0.2-0.6%
Titanium 0-0.1%
Zinc 0-0.10%
Other 0.05-0.15%
