H Channels
Aluminum H channel is an H-shaped profile used to join two panels edge-to-edge or divide a structural assembly — common in paneling and framing wherever two flat surfaces need to connect along a shared edge. Stocked in 6063-T5 alloy, mill finish, in standard 4 ft, 6 ft, 8 ft, and 12 ft lengths, in leg-to-leg openings sized to fit panels from 1/2" up to 2" thick, in wall thicknesses from 1/20" to 1/4". The center web keeps both panel edges aligned during assembly.
Aluminum H Channel 1-1/8" x 1-23/32" x 1/20" – Fits 1" – 6063-T5
- Height
- 1-23/32"
- Width
- 1-1/8"
- Fit
- 1"
- Wall Thickness
- 1/20"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6311251719050-72M | Cut Length: 72"; Finish: Mill Finish | $27.60 | In stock |
| H6311251719050-96M | Cut Length: 96"; Finish: Mill Finish | $35.44 | In stock |
| H6311251719050-48M | Cut Length: 48"; Finish: Mill Finish | $19.14 | In stock |
| H6311251719050-144M | Cut Length: 144"; Finish: Mill Finish | $51.26 | In stock |
Aluminum H Channel 1-1/32" x 1-1/2" x 1/16" – Fits 29/32" – 6063-T5
- Height
- 1-1/2"
- Width
- 1-1/32"
- Fit
- 29/32"
- Wall Thickness
- 1/16"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6310321500063-72M | Cut Length: 72"; Finish: Mill Finish | $31.51 | In stock |
| H6310321500063-48M | Cut Length: 48"; Finish: Mill Finish | $20.87 | In stock |
| H6310321500063-96M | Cut Length: 96"; Finish: Mill Finish | $42.43 | In stock |
| H6310321500063-144M | Cut Length: 144"; Finish: Mill Finish | $68.06 | In stock |
Aluminum H Channel 2-1/8" x 1-1/2" x 1/16" – Fits 2" – 6063-T5
- Height
- 1-1/2"
- Width
- 2-1/8"
- Fit
- 2"
- Wall Thickness
- 1/16"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6321251500063-72M | Cut Length: 72"; Finish: Mill Finish | $37.05 | In stock |
| H6321251500063-48M | Cut Length: 48"; Finish: Mill Finish | $25.69 | In stock |
| H6321251500063-96M | Cut Length: 96"; Finish: Mill Finish | $53.41 | In stock |
| H6321251500063-144M | Cut Length: 144"; Finish: Mill Finish | $68.81 | In stock |
Aluminum H Channel 1" x 2-3/8" x 1/4" – Fits 1/2" – 6063-T5
- Height
- 2-3/8"
- Width
- 1"
- Fit
- 1/2"
- Wall Thickness
- 1/4"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6310002375250-72M | Cut Length: 72"; Finish: Mill Finish | $219.53 | In stock |
| H6310002375250-48M | Cut Length: 48"; Finish: Mill Finish | $152.21 | In stock |
| H6310002375250-96M | Cut Length: 96"; Finish: Mill Finish | $340.07 | In stock |
| H6310002375250-144M | Cut Length: 144"; Finish: Mill Finish | $407.70 | In stock |
Aluminum H Channel 11/16" x 1-1/16" x 1/20" – Fits 19/32" – 6063-T5
- Height
- 1-1/16"
- Width
- 11/16"
- Fit
- 19/32"
- Wall Thickness
- 1/20"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6306881063050-72M | Cut Length: 72"; Finish: Mill Finish | $18.36 | In stock |
| H6306881063050-48M | Cut Length: 48"; Finish: Mill Finish | $12.73 | In stock |
| H6306881063050-96M | Cut Length: 96"; Finish: Mill Finish | $26.47 | In stock |
| H6306881063050-144M | Cut Length: 144"; Finish: Mill Finish | $34.11 | In stock |
Aluminum H Channel 7/8" x 1-1/2" x 3/16" – Fits 1/2" – 6063-T5
- Height
- 1-1/2"
- Width
- 7/8"
- Fit
- 1/2"
- Wall Thickness
- 3/16"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6308761500188-72M | Cut Length: 72"; Finish: Mill Finish | $88.17 | In stock |
| H6308761500188-48M | Cut Length: 48"; Finish: Mill Finish | $57.38 | In stock |
| H6308761500188-96M | Cut Length: 96"; Finish: Mill Finish | $106.27 | In stock |
| H6308761500188-144M | Cut Length: 144"; Finish: Mill Finish | $203.86 | In stock |
Aluminum H Channel 2" x 2" x 1/8" – Fits 1-3/4" – 6063-T5
- Height
- 2"
- Width
- 2"
- Fit
- 1-3/4"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6320002000125-72M | Cut Length: 72"; Finish: Mill Finish | $109.93 | In stock |
| H6320002000125-48M | Cut Length: 48"; Finish: Mill Finish | $65.52 | In stock |
| H6320002000125-96M | Cut Length: 96"; Finish: Mill Finish | $141.15 | In stock |
| H6320002000125-144M | Cut Length: 144"; Finish: Mill Finish | $204.16 | In stock |
Aluminum H Channel 11/16" x 1-1/2" x 3/32" – Fits 1/2" – 6063-T5
- Height
- 1-1/2"
- Width
- 11/16"
- Fit
- 1/2"
- Wall Thickness
- 3/32"
- Alloy & Temper
- 6063-T5
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 60 BHN
- Hardness - Rockwell (Scale E)
- 67
- Hardness - Webster
- ≥ 7
- Country of Origin
- United States of America
- materials
- Aluminum 95.1%
- materials
- Chromium 0-0.1%
- materials
- Copper 0-0.1%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.45-0.90%
- materials
- Manganese 0-0.10%
- materials
- Silicon 0.2-0.6%
- materials
- Titanium 0-0.1%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| H6306881500094-72M | Cut Length: 72"; Finish: Mill Finish | $40.16 | In stock |
| H6306881500094-48M | Cut Length: 48"; Finish: Mill Finish | $28.69 | In stock |
| H6306881500094-96M | Cut Length: 96"; Finish: Mill Finish | $53.13 | In stock |
| H6306881500094-144M | Cut Length: 144"; Finish: Mill Finish | $81.87 | In stock |
