Hex Tubes
Aluminum hex tube is hollow stock with a hexagonal cross-section, used in specialty fixtures and mechanical fit-up applications that need a hex-shaped hollow section to mate with hex-drive hardware or fittings. Stocked in 6061-T6 alloy, mill finish, in standard 4 ft, 6 ft, 8 ft, and 12 ft lengths, in across-flats sizes from 1/2" to 1-1/2", in 1/8" and 1/4" wall thicknesses — the hollow section cuts weight versus solid hex bar wherever the application doesn't need a fully solid cross-section.
Aluminum Hex Tube 1/2" x 1/8" – 6061-T6
- Width
- 1/2"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT610500125-72M | Cut Length: 72"; Finish: Mill Finish | $29.63 | In stock |
| HT610500125-48M | Cut Length: 48"; Finish: Mill Finish | $19.20 | In stock |
| HT610500125-96M | Cut Length: 96"; Finish: Mill Finish | $35.33 | In stock |
| HT610500125-144M | Cut Length: 144"; Finish: Mill Finish | $54.27 | In stock |
Aluminum Hex Tube 5/8" x 1/8" – 6061-T6
- Width
- 5/8"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT610625125-72M | Cut Length: 72"; Finish: Mill Finish | $37.09 | In stock |
| HT610625125-48M | Cut Length: 48"; Finish: Mill Finish | $25.60 | In stock |
| HT610625125-96M | Cut Length: 96"; Finish: Mill Finish | $47.10 | In stock |
| HT610625125-144M | Cut Length: 144"; Finish: Mill Finish | $67.93 | In stock |
Aluminum Hex Tube 3/4" x 1/8" – 6061-T6
- Width
- 3/4"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT610750125-72M | Cut Length: 72"; Finish: Mill Finish | $45.59 | In stock |
| HT610750125-48M | Cut Length: 48"; Finish: Mill Finish | $31.35 | In stock |
| HT610750125-96M | Cut Length: 96"; Finish: Mill Finish | $58.61 | In stock |
| HT610750125-144M | Cut Length: 144"; Finish: Mill Finish | $83.98 | In stock |
Aluminum Hex Tube 1" x 1/8" – 6061-T6
- Width
- 1"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT611000125-72M | Cut Length: 72"; Finish: Mill Finish | $60.85 | In stock |
| HT611000125-48M | Cut Length: 48"; Finish: Mill Finish | $43.19 | In stock |
| HT611000125-96M | Cut Length: 96"; Finish: Mill Finish | $86.02 | In stock |
| HT611000125-144M | Cut Length: 144"; Finish: Mill Finish | $125.78 | In stock |
Aluminum Hex Tube 1-1/4" x 1/8" – 6061-T6
- Width
- 1-1/4"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT611250125-72M | Cut Length: 72"; Finish: Mill Finish | $78.24 | In stock |
| HT611250125-48M | Cut Length: 48"; Finish: Mill Finish | $55.98 | In stock |
| HT611250125-96M | Cut Length: 96"; Finish: Mill Finish | $104.37 | In stock |
| HT611250125-144M | Cut Length: 144"; Finish: Mill Finish | $167.34 | In stock |
Aluminum Hex Tube 1-1/2" x 1/8" – 6061-T6
- Width
- 1-1/2"
- Wall Thickness
- 1/8"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT611500125-72M | Cut Length: 72"; Finish: Mill Finish | $109.20 | In stock |
| HT611500125-48M | Cut Length: 48"; Finish: Mill Finish | $70.41 | In stock |
| HT611500125-96M | Cut Length: 96"; Finish: Mill Finish | $130.39 | In stock |
| HT611500125-144M | Cut Length: 144"; Finish: Mill Finish | $250.03 | In stock |
Aluminum Hex Tube 1" x 1/4" – 6061-T6
- Width
- 1"
- Wall Thickness
- 1/4"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT611000250-72M | Cut Length: 72"; Finish: Mill Finish | $109.41 | In stock |
| HT611000250-48M | Cut Length: 48"; Finish: Mill Finish | $79.74 | In stock |
| HT611000250-96M | Cut Length: 96"; Finish: Mill Finish | $170.09 | In stock |
| HT611000250-144M | Cut Length: 144"; Finish: Mill Finish | $250.77 | In stock |
Aluminum Hex Tube 1-1/2" x 1/4" – 6061-T6
- Width
- 1-1/2"
- Wall Thickness
- 1/4"
- Alloy & Temper
- 6061-T6
- Extrusion Manufacturing Compliance
- ASTM B221-14
- RoHS Compliance Standards
- RoHS 3 (2017/2102/EU) Compliant
- DFARS Compliance Standards
- Specialty Metals COTS-Exempt
- Hardness - Brinell
- 95 BHN
- Hardness - Rockwell (Scale E)
- 93
- Hardness - Webster
- ≥ 15
- Country of Origin
- United States of America
- materials
- Aluminium 95.85%
- materials
- Chromium 0.04-0.35%
- materials
- Copper 0.15-0.4%
- materials
- Iron 0-0.7%
- materials
- Magnesium 0.8-1.2%
- materials
- Manganese 0-0.15%
- materials
- Nickel 0-0.5%
- materials
- Silicon 0.4-0.6%
- materials
- Titanium 0-0.15%
- materials
- Zinc 0-0.25%
| SKU | Options | Price (each) | Availability |
|---|---|---|---|
| HT611500250-72M | Cut Length: 72"; Finish: Mill Finish | $216.00 | In stock |
| HT611500250-48M | Cut Length: 48"; Finish: Mill Finish | $140.53 | In stock |
| HT611500250-96M | Cut Length: 96"; Finish: Mill Finish | $260.23 | In stock |
| HT611500250-144M | Cut Length: 144"; Finish: Mill Finish | $499.27 | In stock |
